LED Bar with 8 comparators

Author: Prof. Dr. Marco Gottardo
Email:  [email protected]

Prof. Dr. Marco Gottardo
Project Code Short Description Image

LED Bar with 8 comparators

Bar LED made ​​with two LM324 chips, then with 8 comparators and many levels of signaling devices. Designed for educational use is actually very useful as a signal output level of an adjustable alimentatore to indicate the level of a tank etc. etc..

download file FidoCad (compared to 8 levels)

LED Bar with 8 comparators PCB Layout

Check availability of the PCB or by writing for the assembled projects to
